PMQW04 Multi-angle Planetary Ball Mill

PMQW04 Multi-angle Planetary Ball Mill is an essential device for mixing, fine grinding, sample preparation, nano-materials dispersion, new product development and small batch production of high-tech materials. With small size, full-feature, high efficiency and low noise, this product is an ideal instrument for scientific research institutions, higher institutes and corporate research laboratories to obtain the micro-particle samples (four samples can be obtained in one experiment). This instrument can grind and mix samples of different sizes or materials during dry and wet conditions. The smallest particle discharged is 0.1um (namely1 ×10mm-4). Multi-angle Planetary ball mills are widely used in geology, mining, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, beauty, environmental protection and other departments.

Working principle

A turntable is equipped with four milling cans. When the turntable rotates, the milling cans revolve both around the wheel axis and on their own axis, like planetary movement.At the same time, they also flip 360 ° in the context of a three-dimensional space and can be artificially set up to run stably in any direction, so as to grind the materials finer and more uniform, and can solve the problems of some materials which often sink or stick to the bottom of cans.

Technical parameters

Application fields: electronic materials, soil, aviation materials, batteries, ceramics, biology, geology and minerals, metallurgy,etc.

Applicated samples: soft, hard, brittle, fibrous, dry or wet

Work platforms: 4

Working method: Parallel rotation grinding or 360°flip grinding and fixed point operation

Maximum feed volume: 2/3 of the of the grinding jar

Maximum feed size: soil material ≤ 10mm, other materials ≤ 3mm

Final fineness: up to 0.1μm

Alternate timing: 1-9999min

Speed: revolution: 300r/min,  rotation: 600r/min

Grinding jar：50ml, 100ml

Vacuum jar: 50ml

Power: AC220V/50~60Hz

Data storage: can store 20 sets of different process data

Data monitoring: Real time monitoring of operational status, supporting fault alarms

Programmable operation: 6 sets of programmable operation steps

Control mode: 7 "Chinese-English interchangeable graphical HMI, programmable multiple operation modes (forward and reverse alternating operation, interval operation, timed operation), data storage and memory function (supporting editing, updating, deleting, and creating)

Jar material: stainless steel, vacuum stainless steel, agate, zirconia, alumina, PTFE, nylon, tungsten carbide，etc.

Certifications: CE certificate(machine),  UL certificate(electronic components)
